[RAW] 1 x LD1117 LD1117AV33 3.3V TO-220 Voltage Regulator 1.2A STMicroelectronics
Category: RAW MATERIALS
$0.00
In Stock
SKU: LM1117AV33-001
This pack includes one STMicroelectronics LM1117T-3.3 Voltage Regulators, delivering a fixed 3.3V output at up to 1.2A (800mA typical) from a 4.5V–15V input.
Housed in a TO-220 package (10mm x 4.5mm x 9.4mm), they feature thermal shutdown and current limiting, operating from 0°C to +125°C. Suitable for powering microcontrollers, battery devices, repairs, and educational projects, a heatsink is recommended above 800mA.
Pacific Custom Engineering ensures authentic components.
Free & fast shipping from Washington State
The LM1117T-3.3 Voltage Regulator is provided in a pack of one, featuring a low-dropout (LDO) linear voltage regulator in a TO-220 package. It delivers a fixed output voltage of 3.3V with a maximum output current of 1.2A, designed to regulate input voltages ranging from 4.5V to 15V.
The regulator has a typical dropout voltage of 1.2V at 800mA, requiring an input voltage at least 1.2V above the output for proper regulation (minimum 4.5V).
It is housed in a 3-pin TO-220 package measuring approximately 10mm x 4.5mm x 9.4mm, with a tab for heatsink mounting to manage thermal dissipation.
The LM1117T-3.3 includes internal protection features such as thermal shutdown and current limiting, ensuring safe operation under typical conditions. It operates within a temperature range of 0°C to +125°C and requires a minimum 10µF tantalum capacitor at the output to improve transient response and stability.
This component is commonly used in circuits requiring a stable 3.3V supply, such as those powering microcontrollers or sensors.
Key Features:
- Output Voltage: 3.3V – Provides a stable 3.3V supply for low-voltage circuits.
- Output Current: Up to 1.2A – Suitable for powering small devices, though continuous use above 800mA requires a heatsink.
- Input Voltage: 4.5V to 15V – Requires at least 4.5V input for proper regulation.
- Package: TO-220, 3-pin, approximately 10mm x 4.5mm x 9.4mm – Standard for through-hole mounting.
- Protection: Includes thermal shutdown and current limiting – Enhances safety during operation.
- Operating Temperature: 0°C to +125°C – Suitable for typical indoor environments.
- Dropout Voltage: Typically 1.2V at 800mA – Ensures stable output with sufficient input voltage.
Common Applications:
- Power Supply Regulation: Provides a stable 3.3V supply for microcontrollers, such as Arduino or Raspberry Pi, in DIY electronics.
- Battery-Powered Devices: Regulates battery output (e.g., 5V or 9V) to 3.3V for sensors or small modules.
- Electronics Repair: Replaces faulty regulators in power supplies, consumer electronics, or industrial equipment.
- Educational Projects: Used in electronics courses to teach voltage regulation principles.
- Circuit Prototyping: Supplies consistent 3.3V power for breadboard or PCB prototypes.
Specifications:
- Brand: STMicroelectronics
- Model: LM1117T-3.3 (LD1117)
- Output Voltage: 3.3V
- Output Current: 1.2A (max, 800mA typical per datasheet)
- Input Voltage: 4.5V to 15V
- Package: TO-220, 3-pin
- Dimensions: Approximately 10mm x 4.5mm x 9.4mm
- Operating Temperature: 0°C to +125°C
- Dropout Voltage: 1.2V at 800mA (typical)
- Quantity: 10 pieces per pack
Quality Assurance:
Pacific Custom Engineering supplies genuine STMicroelectronics components, ensuring consistent performance for various circuit applications.
